Models	Flow (L/min)	Flow (US Gpm)	Pressure (MPa)	Pressure (bar)	Pressure (psi)	MAX Pressure (MPa)	MAX Pressure (bar)	MAX Pressure (psi)	Jet reaction thrust (N)	Single-phase motor power (kW)	Single-phase motor power (V)	Single-phase motor power (Hz)	Single-phase motor power (A)	Overall dimensions L x l x h (mm)	Weight (kg)
TSX 10.130.2	9.5	2.5	13	130	1885	16	160	2300	< 29	3.2	230-1	50	14.7	860x400x875	44,5 ÷ 54	Enter
TSX 10.130.4	9.5	2.5	13	130	1885	16	160	2300	< 29	3.2	240-1	50	13.6	860x400x875	44,5 ÷ 54	Enter
TSX 12.100.2	12	3.2	10	100	1450	13	130	1885	< 32	3.2	230-1	50	14.7	860x400x875	44,5 ÷ 54	Enter
TSX 12.100.4	12	3.2	10	100	1450	13	130	1885	< 32	3.2	230-1	50	14.7	860x400x875	44,5 ÷ 54	Enter
TSX 12.140.2	12	3.2	14	140	2030	17	170	2450	< 40	3.8	230-3	50	12.5	860x400x875	44,5 ÷ 54	Enter
TSX 12.140.3	12	3.2	14	140	2030	17	170	2450	< 40	3.8	400-3	50	7.2	860x400x875	44,5 ÷ 54	Enter
TSX 14.120.2	14	3.7	12	120	1740	15	150	2175	< 41	3.8	230-3	50	12.5	860x400x875	44,5 ÷ 54	Enter
TSX 14.120.3	14	3.7	12	120	1740	15	150	2175	< 41	3.8	400-3	50	7.2	860x400x875	44,5 ÷ 54	Enter
TSX 13.180.2	13	3.4	18	180	2610	21	210	2950	< 47	5	230-3	50	15.8	860x400x875	44,5 ÷ 54	Enter
TSX 13.180.3	13	3.4	15	150	2175	18	180	2610	< 49	5	400-3	50	9.2	860x400x875	44,5 ÷ 54	Enter
13.180.4	13	3.4	18	180	2610	21	210	2950	< 47	5	240-3	50	8.5	860x400x875	44,5 ÷ 54	Enter
13.180.5	13	3.4	18	180	2610	21	210	2950	< 47	5	415-3	50	8.5	860x400x875	44,5 ÷ 54	Enter
TSX 15.150.2	15	4	15	150	2175	18	180	2610	< 49	5	230-3	50	15.8	860x400x875	44,5 ÷ 54	Enter
TSX 15.150.3	15	4	15	150	2175	18	180	2610	< 49	5	400-3	50	9.2	860x400x875	44,5 ÷ 54	Enter
TSX 15.150.4	15	4	15	150	2175	18	180	2610	< 49	5	240-3	50	14.5	860x400x875	44,5 ÷ 54	Enter
TSX 15.150.5	15	4	15	150	2175	18	180	2610	< 49	5	415-3	50	8.5	860x400x875	44,5 ÷ 54	Enter
TSX 17.130.2	17	4.5	13	130	1885	16	160	2300	< 51	5	230-3	50	15.8	860x400x875	44,5 ÷ 54	Enter
TSX 17.130.3	17	4.5	13	130	1885	16	160	2300	< 51	5	400-3	50	9.2	860x400x875	44,5 ÷ 54	Enter
TSX 17.130.4	17	4.5	13	130	1885	16	160	2300	< 51	5	240-3	50	14.5	860x400x875	44,5 ÷ 54	Enter
TSX 17.130.5	17	4.5	13	130	1885	16	160	2300	< 51	5	415-3	50	8.5	860x400x875	44,5 ÷ 54	Enter
TSX 951.6	11.5	3	10.3	103	1500	13.3	133	1929	< 31	3.2	220-1	60	15.5	860x400x875	44,5 ÷ 54	Enter
TSX 954.6	13.6	3.6	9	90	1300	12	120	1740	< 35	3.2	200-3	60	12	860x400x875	44,5 ÷ 54	Enter
TSX 955.6	13	3.4	11	110	1600	14	140	2030	< 37	3.4	200-3	60	12	860x400x875	44,5 ÷ 54	Enter
TSX 956.6	13	3.4	14.5	145	2100	17.5	17	2538	< 41	4.6	220-3	60	16.5	860x400x875	44,5 ÷ 54	Enter
TSX 957.6	15.9	4.2	7.6	76	1100	10.6	106	1537	< 37	3.2	220-1	60	15.5	860x400x875	44,5 ÷ 54	Enter
TSX 961.6	15	4	15	150	2175	18	180	2610	< 49	5	220-3	60	15.8	860x400x875	44,5 ÷ 54	Enter
TSX 961.8	15	4	15	150	2175	18	180	2610	< 49	5	380-3	60	9.2	860x400x875	44,5 ÷ 54	Enter

TSX
