Models	Flow (L/min)	Flow (US Gpm)	Pressure (MPa)	Pressure (bar)	Pressure (psi)	MAX Pressure (MPa)	MAX Pressure (bar)	MAX Pressure (psi)	Jet reaction thrust (N)	Single-phase motor power (kW)	Single-phase motor power (V)	Single-phase motor power (Hz)	Single-phase motor power (A)	Overall dimensions L x l x h (mm)	Weight (kg)
BOXJET TURBO 11-50	11	2.9	5	50	725	8	80	1160	20	1,68 / 1,64	230 / 240	50	8,2 / 8	360x240x235	18.5	Enter
BOXJET TURBO 8-70	8	2.11	7	70	1015	10	100	1450	< 20	1,68 / 1,64	230 / 240	50	8,2 / 8	360x240x235	18.5	Enter
BOXJET TURBO 8-90	8	2.11	9	90	1300	12	120	1750	20	1.86	230 / 240	50	8,6 / 8,4	360x240x235	18.7	Enter
BOXJET TURBO 15	8	2.11	5.5	55	800	8.5	85	1235	< 20	1.36	100	50	15	360x240x235	18.6	Enter
BOXJET TURBO 19	8	2.11	6	60	870	9	90	1300	< 20	1.4	100	60	15	360x240x235	19.4	Enter
BOXJET TURBO 21	8	2.11	7	70	1015	10	100	1450	< 20	1.58	115	60	15	360x240x235	21.4	Enter

BOXJET

Documenti tecnici
